The Terminal Rotation Test Setup is specially designed to determine the mechanical strength and integrity of terminals in plugs, sockets, and similar electrical accessories. It verifies whether terminals can withstand the required torque without loosening, cracking or showing signs of damage. This test is mandatory as per IS:1293-2019 for ensuring long-term safety and reliability of electrical accessories.
The apparatus consists of a rigid clamping fixture, torque application arrangement, and calibrated weights or torque arm to apply precise rotational force to the terminal under test.
Testronix Instruments is leading manufacturer and supplier of Terminal Rotation Test Setup in India. To get the best price, request a quote or call us now!
Standards-Compliant – Fully designed as per IS and IEC terminal torque test requirements.
Accurate Torque Application – Lever-arm with calibrated weights ensures precise and repeatable results.
Robust Fixtures – Universal clamping setup for different plug and socket terminals.
Durable Design – Heavy-duty powder-coated frame for long service life.
Compact & User-Friendly – Small footprint with simple manual operation.
Standard Compliance: IS:1293-2019, IEC 60884-1
Torque Application: Lever arm with provision for applying calibrated weights
Torque Range: 0.1 Nm to 0.5 Nm (as per standard requirements)
Fixtures:
• Rigid socket/plug clamping fixture
• Adjustable terminal holding grips
Weight Set: Calibrated weights for torque application (typically 0.5 N to 5 N depending on arm length)
Construction: Powder-coated mild steel structure with precision machined components
Operation: Manual torque application using lever arm & weights
Safety: Non-slip clamping, insulated fixtures for operator protection
