PC-Based Standing Loss Test Apparatus with Test Corner (4-Station)
PC-Based Standing Loss Test Apparatus with Test Corner (4-Station)

PC-Based Standing Loss Test Apparatus with Test Corner (4-Station)

4.7 of 5      In Stock
Model No: HAP21

  • Brand:

  • Testronix Instruments

This apparatus measures the standing loss (no-load power consumption) of appliances like fans, motors, and transformers when connected to a supply but not under load. The 4-sta..

4500+ Happy Customers
Description

This apparatus measures the standing loss (no-load power consumption) of appliances like fans, motors, and transformers when connected to a supply but not under load. The 4-station setup allows simultaneous testing with digital meters and data acquisition software.

Features
  • Tests idle power losses under stable input voltage
  • Evaluates energy efficiency and standby power compliance
  • Multi-appliance testing boosts lab productivity
  • Accurate digital meters for low current/voltage readings
  • Exportable reports with timestamped logs for BIS validation
Specifications

Parameter

Specification

Test Stations

4 (independent, isolated)

Power Measurement

Digital KWH Meter for each station

Temperature Monitoring

Digital thermometer (optional)

Voltage Range

0–300 V AC

Control Interface

PC-based software for monitoring & reporting

Construction

Test corner with 20 mm plywood isolation
