The Cord Flexing Tester is designed to evaluate the mechanical durability and safety performance of flexible electrical cords used in household and commercial appliances. It simulates repeated flexing under controlled load, angle, and speed to replicate real-world bending stresses as specified in IS 302-1 Clause 25.14.
Testronix Instruments is leading manufacturer and supplier of Cord Flexing Tester in India. To get the best price, request a quote or call us now!
The system features adjustable clamps, programmable cycle count, a geared motor drive, and a digital counter to ensure accurate, repeatable testing. It helps manufacturers verify cord reliability, endurance, and long-term usability.
Standard: IS 302-1, Clause 25.14
Purpose
To evaluate the mechanical durability of flexible cords under repeated flexing.
Adjustable flexing angle from ±45° to ±90°
Flexing speed 60 cycles/min (as per IS 302-1)
Programmable cycle count up to 999,999
Load options 50 N / 100 N depending on appliance category
Adjustable cord clamps (Ø3–Ø12 mm)
Adjustable sample fixture up to 200 mm
Heavy-duty 0.25 HP geared motor
Digital cycle counter with emergency stop
Steel test arms with ball-bearing pivot
Adjustable speed drive
Operates on 230 V AC, 50 Hz
|
Parameter |
Specification |
|
Flexing Angle |
±45° to ±90° adjustable |
|
Flexing Speed |
60 cycles/min (as per IS 302-1) |
|
Number of Cycles |
10,000–20,000 cycles, programmable up to 999,999 |
|
Load on Cord |
50 N or 100 N (as per appliance requirement) |
|
Clamp Type |
Adjustable cord clamps (Ø3–Ø12 mm), fixture adjustable up to 200 mm |
|
Motor |
0.25 HP geared motor |
|
Control |
Digital cycle counter + emergency stop |
|
Test Arms |
Steel with ball-bearing pivot |
|
Power Supply |
230 V AC, 50 Hz |
|
Speed Drive |
Adjustable |
