Benchtop Spectrophotometer Manufacturer at Price in India

Description

This equipment is particularly important in industries where visual properties like gloss, opacity, and transparency influence consumer perception and product functionality. By providing accurate measurements of reflectance and transmittance, the spectrophotometer enables precise formulation, quality control, and compliance with global standards (CIE, ASTM, ISO). Its robust design, multiple measurement apertures, and advanced data analysis capabilities make it a critical tool for research labs, production units, and quality assurance departments.

Testronix Instruments is a leading manufacturer and supplier of Benchtop Spectrophotometer in India. For the best price, contact us for a quote or call now!

Features

High-precision CMOS sensor delivers accurate color measurement for both reflectance and transmittance.
Dual optical geometry (d/8 & d/0) ensures reliable results across opaque and transparent materials.
Multiple interchangeable apertures allow precise testing of different sample sizes.
Wide illuminant and observer angle options simulate real-life viewing conditions.
Fast measurement speed boosts efficiency in labs and production environments.
Excellent repeatability and inter-instrument agreement guarantee consistent quality control.
7-inch touchscreen interface makes operation simple and user-friendly.
Large data storage with USB & Bluetooth ensures smooth data handling and connectivity.
Long-life LED light source provides stable performance with minimal maintenance.
Compliance with global standards (CIE, ISO, ASTM, DIN) makes it suitable for worldwide use.

Specifications

Parameter	Specification
Illuminant	360nm-780nm Combined LED Lamp, 400nm cut-off
Sensor	256 Image Element Double Array CMOS Image Sensor
Wavelength Pitch	10 nm
Semiband Width	10 nm
Reflectance Range	0-200%
Measuring Aperture	Reflective: Φ30mm/Φ25.4mm, Φ18mm/Φ15mm, Φ10mm/Φ8mm, Φ6mm/Φ4mm; Transmissive: Φ30mm, Φ25.4mm
Integrating Sphere Size	Φ 154mm
Optical Geometry	Reflectance: d/8 (SCI&SCE; Include UV/Exclude UV); Transmittance: d/0 (SCI&SCE; Include UV/Exclude UV)
Conformance	CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7
Color Space	CIE LAB, XYZ, Yxy, LCh, CIE LUV, Musell, s-RGB, HunterLab, βxy, DIN Lab99
Color Difference Formula	?E ab, ?E uv, ?E 94, ?E cmc(2:1), ?E cmc(1:1), AE 00, DIN?E99, ?E(Hunter)
Observer	2° / 10°
Illuminants	D65, A, C, D50, D55, D75, F1-F12
Measurement Time	About 3 s (Measure SCI & SCE about 6s)
Repeatability	Spectral reflectance: Φ25.4mm/SCI, SD within 0.05% (400-700 nm: within 0.04%); Chromaticity value: Φ25.4mm/SCI, SD ?Eab within 0.02; Spectral Transmittance: Φ25.4mm/SCI, SD within 0.05% (400-700 nm: within 0.04%); Chromaticity value: Φ25.4mm/SCI, SD within ?Eab 0.03
Inter-instrument Error	Φ25.4mm/SCI, Within ?E*ab 0.15 (Average for 12 BCRA Series II color tiles)
Working Environment	Temperature: 0~40°C; Humidity: 0~85% (No Condensation)
Storage Environment	Temperature: -20~50°C; Humidity: 0~85% (No Condensation)
Data Storage Capacity	Standard 5000 Pcs, Sample 40000 Pcs (one PCS can include both SCI and SCE)
Light Source Device Life	5 years, more than 3 million times measurements
Screen	7" TFT Capacitive Screen-touch Display
Data Port	USB & Bluetooth
Standard Accessory	Power adaptor , manual, standard calibration plate, Checking Green Board, Sample Holder, Φ4 mm, Φ8 mm, Φ15 mm, Φ25.4mm ,USB Cable, User Guide, PC Software, Transmissive Test fixture Assembly
Size	370x300x200 mm
Weight	9.6 kg
Power Supply	DC 24V, 3A Power Adapter
