HMI-Based Endurance Test Apparatus for IS 374 (Ceiling Fans) Price and Manufacturer in India

HMI-Based Endurance Test Apparatus for IS 374 (Ceiling Fans)

4.7 of 5 In Stock

Model No: HAP20

Brand:

Testronix Instruments

This apparatus is designed to test the electrical and mechanical endurance of ceiling fans in compliance with IS 374. It automates ON/OFF cycles, voltage variation, and speed r..

4500+ Happy Customers

Description

This apparatus is designed to test the electrical and mechanical endurance of ceiling fans in compliance with IS 374. It automates ON/OFF cycles, voltage variation, and speed regulation over extended durations. The HMI interface allows full control and data logging for performance tracking.

Features

Tailored specifically for IS 374 ceiling fan endurance compliance
Simulates real-world switching and speed control cycles
Tracks energy usage, voltage fluctuations, and runtime performance
HMI provides easy monitoring, diagnostics, and data export
Integrated overload protection and automated cut-off system

Specifications

Parameter	Specification
Voltage Range	0–500 V AC
Power Capacity	0–2000 W
On/Off Timer	Programmable (0–99 hours)
Cycle Counter	Digital, 0–999999 cycles
Hour Meter	Real-time runtime recording
Variac Capacity	10 Amp (manual or motorized control)
Control System	HMI with PLC interface
