Peel | Seal | Bond | Adhesion Strength Tester Digital




Peel | Seal | Bond | Adhesion Strength Tester Digital

4.7 of 5      In Stock

Model No: TX-PBT 200

  • Brand:

  • Testronix Instruments

The Peel Seal bond Adhesion Strength Tester is an innovative instrument which helps in measuring the adhesion Strength or peel ability of self-adhesive pressure sensitive materials. Peel adhesion tester is defined as the force required to test the strength of the adhesives.
The instrument consists of two jaws that are used for holding the sample. The specimen is placed between two movable cl


Need more information or have a question?

Contact Us

The Peel Seal bond Adhesion Strength Tester is an innovative instrument which helps in measuring the adhesion Strength or peel ability of self-adhesive pressure sensitive materials. Peel adhesion tester is defined as the force required to test the strength of the adhesives.
The instrument consists of two jaws that are used for holding the sample. The specimen is placed between two movable clamps. This applies a force on the sample and peels it off from the surface. The force that is required to peel off the sample from the surface is recorded by the highly accurate load cell given with the equipment. The force applied is displayed on the digital display provided in the machine. This instrument hence can provide the most accurate data analysis so that the manufacturers could provide the best quality to their customers
The Peel Strength Tester is one of the most popular testing instruments that is used in the packaging and adhesive industries to test the strength of the adhesives. The following tests can be conducted on one single instrument:
1.    Adhesive strength test
2.    Peel strength tester
3.    Seal strength test
4.    Bond strength test
The instrument complies with various tester standards such as Standards – ASTM D429 – 14, ASTM D903
Available models: Peel/ adhesion/ bond/ seal strength tester Computerized


Working principle of peel/ seal strength tester

The peel/ seal strength tester is manufactured with highly futuristic arrangements as the instrument determines the peel ability of two materials bonded together. The instrument is equipped with two movable jaws that clamp the specimen firmly and move in opposite directions to each other in a linear motion, forcing peel strength on the specimen and determining the peel ability of the same. The peak load that a specimen can withstand is indicated on a microprocessor-based digital display, allowing the operator to achieve highly precise test results. The instrument conducts peel, seal, bond & adhesion tests.

Applications of peel/ seal/bond strength tester

  • Textile industry
  • Flexible packaging items
  • Bond strength of tapes
  • Adhesive strength

Advantages of peel/ seal strength tester

The peel/ seal strength tester is a very crucial lab testing instrument designed to help manufacturers from the flexible paper & packaging industry determine the peel ability of tapes, adhesive material, etc. to withstand peel strength. Achieving a certain level of peel strength provides a sense of assurance and safety in the minds of manufacturers as these materials are used for packaging products and act as a shielding layer. The instrument’s ergonomic design contributes to the quick & accurate test results of various materials repeatedly.



Testronix Instruments is a leading manufacturers and supplier of Peel, Seal, Bond and Adhesion Strength Tester in India. For the best price, contact us for a quote or call now!

    • Microprocessor based display for accurate test results
    • Display for Peel Adhesive strength of test specimen
    • Memory to hold up to 9 test reading
    • Strong gripping clamps to perform Peel test at 180 degree.
    • Dimensions: 600x500x1120 mm
    • Material: Powder coated mild steel

    Optional and additional accessories:
    1.    Computerized model
    2.    Speed drive for accurate results
    3.    90 degree fixture

    • Load Cell Capacity: 20 Kgf
    • Display: LED (Digital)
    • Accuracy: ± 0.5% within entire range.
    • Least Count/Resolution:  0.002Kgf
    • Power: 220V, Single phase, 50 Hz
    • Speed:  300 mm/min ± 5%


With the purchase of Peel Tester from Testronix , it has become super advanced to check the adhesion strength of my tapes and films that i use in my industry .

George Mathew

A worthy instrument , plus the added feature of 90 degree fixture makes it more efficient.

Prayag Bhardwaj

Superlative quality peel tester. Advanced technology speed drive

Kishan

How Peel | Seal | Bond | Adhesion Strength Tester Digital Works?

View this video to learn how this product works

Have a Question?

Connect with our customer support manager to get the product details & Quote.

Please fill this form to request a call-back from our
customer support manager with pricing and details.

We will also send you our product PDF for your reference.

Call our Experts for the Best Offer
+91 9313140140

Word of Testimony

What our customer says about us is important to us.

Testronix has set up our new lab in all our plants throughout india. They provide value for money and very affordable testing instruments. Their team is highly trained and has good technical knowledge about the products.

Karan Singh

We want to thank your team for such prompt support. Your instruments are very durable. We are impressed with the design engineering. All the products are very easy to operate. The guidance provided by your team is highly appreciated. We look forward to working with an organisation like yours

Manish Aggarwal

Trusted by market leaders —

FAQ's

Q. What is the use of a peel adhesion strength tester?

To put it simply, an Adhesion Testing Instrument is an innovative packaging industry instrument that helps companies to measure the adhesion strength or the peel ability of self-adhesive pressure-sensitive materials. Peel adhesion refers to the force required at any given time to test the strength of the adhesives, labels and other types of Laminates. Adhesion seal strength tester is of great use when a manufacturer wants to provide the best quality to their clients.

Q. What is the price of a peel seal strength tester in India?

The price of a Peel strength tester can differ depending on the model and instrument. While the price range starts from as low as INR 50,000, it can go up to INR 300,000 for high-end instruments. You may find the same product in different price ranges in the market. Most of the cheap products come from unbranded manufacturers/traders with no guarantee while the branded products of reputed manufacturers maintain high quality and come with branded spare parts and motors.

Q. From where to buy a genuine peel seal bond and adhesion strength tester?

You need to find a renowned manufacturer to buy a genuine peel tester. There are several traders in the market, but not everyone is a genuine manufacturer and can provide you with authentic and high-quality products. For that reason, you need to check if they have their own manufacturing unit and dedicated service set up. Customers must always check if the manufacturer has a dedicated and reliable in-house service set up.

Q. How to get a free quotation for peel seal bond and adhesion strength tester?

To get a free price quotation for the peel seal bond and adhesion strength tester you can contact the company with your requirement, details from their mail id and phone number. To get a quotation from Testronix Instruments fill the form with requirements and you will get an instant call-back from the sales for the techno-commercial offer. You can connect with us anytime at +91 9313 140 140 or info@testronixinstruments.com
