Dart Impact Tester

Dart Impact Tester

Dart Impact Tester

4.7 of 5

Model No: TX-DIT 100

Dart Impact tester is designed to determine the impact resistance strength of flexible films. It operates when a falling weighted dart is made to fall on the sample (Flexible film). The instrument helps in calculating the energy required to damage of deform the specimen.

Need more information or have a question?

Contact Us
Product Description

Dart Impact Tester is used in paper, packaging & flexible films industries for calculating the impact of a free falling dart on a plastic film. The force at which the falling dart ruptures the plastic film under certain conditions is calculated. The impact on the films depends on the falling height of the dart and the weight of the dart.


The test can be conducted by various methods. The instrument also consists of a digital LED screen to provide the user with accurate results and to make the test operation easier.


The instrument is easy to operate and adheres to various test standards such as Standard: IS 2508:1984(R2003), ASTM D1709-16A.


Plastic film manufacturers must ensure that the film is resilient and strong enough to withstand the impact of any external forces. Hence the dart impact tester is the most suitable instrument to calculate the impact and force at which a particular weight can rupture the plastic film

Working principle of the dart impact tester

The lab testing instrument is a very vital product for the flexible paper & packaging industry as it aids the manufacturers in checking the impact force of flexible films & laminates. The working principle of the dart impact tester is extremely simple as it drops a dart on the specimen from different heights and measures if the flexible specimen can sustain the load or not.


The instrument derives accuracy because of the provision of dart made up of steel, allowing the manufacturer to test the quality of materials more effectively.

Product Features

    • Built on a rigid metallic base.
    • Electromagnetic Hold and release mechanism for dart
    • Drop Height adjustable clamp
    • Circular annular clamping devices for zero slippage
    • Powder coated mild steel material
    • Dimension: 415x500x2153 mm


    • Inside diameter of clamp: 127mm
    • Release Mechanism: Electro Magnetic.
    • Diameter of dart head : 3 Method A – 38 mm & Method B – 50 mm
    • Height of fall :660 mm and 1524 mm(Adjustable)
    • Maximum weight holding capacity of Dart Holding Mechanism: 2Kg
    • Release Mechanism: Electromagnetic dart hold/release mechanism
    • Clamping Unit: Circular annular clamping unit with zero slippage
    • Single Phase 220 V AC

We are a manufacturer of foil papers and it is a very reliable product , we have recently purchased it for testing impact of free falling dart on our foil papers . The results which we get are very accurate , made the right decision to go for Testronix

Deepak Sharma

Awesome product with a super easy operation method and accuracy

Rajkumar Sharma

This testronix dart impact tester adheres to all ISO and ASTM standards and generates accurate results. The best part is that you get high level accuracy and precision.

Roshni Arora

This is an awesome machine that is easy to operate and user-friendly.

Hasmukh Chudgar

The dart impact tester gave safe operation and being an automatic device, gave a sense of assurance that I don’t have to interfere much in the tester’s functionality. The instrument has a hemispherical head and is held by a strong electromagnetic dart holder, which perfectly carries out the rupturing test. I used it for plastic sheets whereas this can be used to test corrugated paper, carton boards, fibre boards, etc. Since the dart impact tester adheres to all ISO and ASTM standards, it gives value for quality and money both.

Lokesh Jain

How Dart Impact Tester Works?

View this video to learn how this product works?

Have a Question?

Connect with our customer support manager to get the product details & Quote.

Please fill this form to request a call-back from our
customer support manager with pricing and details.

We will also send you our product PDF for your reference.

Call our Experts for the Best Offer
+91 9313140140

Word of Testimony

What our customer says about us is important to us.

The entire team at Testronix is highly professional. They provide timely delivery with world class features in all their instruments. They also provide customised instruments as per the needs of the user which no other dealer/trader can provide. We are very much satisfied with their products

Maneesh Bhatnagar

We are highly impressed with the Quality and support Testronix has provided. Testronix has set up our entire quality testing laboratory and we are fully satisfied with all their instruments. We highly recommend this brand

Vikas Singh

Trusted by market leaders —


Q. What is the use of the Dart Impact tester?

The Dart Impact Tester is used for testing the impact strength flexible films. It is used in the paper, bundling, and types of flexible film industries for computing the effect of a dropping dart on a plastic film. The instrument helps the user in calculating the exact Force which the flexible film can withstand

Q. Why Dart Impact tester is important?

The instrument is easy to operate and conforms to different test norms like Standard: IS 2508:1984(R2003), ASTM D1709-16A. The Dart Impact tester is the most reasonable instrument to compute the effect and power at which a specific weight can crack the plastic film and is hence so important.

Q. What is the price of Dart Impact tester in India?

The price of Dart impact tester can differ depending on the model and instrument. You may find the same product in different price ranges in the market. Most of the cheap products come from unbranded manufacturers/traders with no guarantee while the branded products of reputed manufacturers maintain high quality and come with a branded spares parts

Q. From where to buy a genuine Dart Impact tester?

You need to find a renowned manufacturer to buy a genuine dart impact tester There are several traders in the market, but not everyone is a genuine manufacturer and can provide you with authentic and high-quality products. For that reason, you need to check if they have their own manufacturing unit and dedicated service set up. Customers must always check if the manufacturer has a dedicated and reliable in-house service set up.

Q. How to get a free quotation for Dart Impact tester?

To get a free price quotation for dart impact tester you can contact the company with your requirement, details from their mail id and phone number. To get a quotation from Testronix Instruments fill the form with requirements and you will get an instant call-back from the sales for the techno-commercial offer. You can connect with us anytime at +91 9313 140 140 or info@testronixinstruments.com
