Cone Crush Tester is designed to evaluate the crushing resistance of conical paper cups & similar cone-shaped paper products. It measures the force required to deform or crush the specimen under a controlled compressive load, helping manufacturers assess product strength, structural integrity & consistency.
Testronix Instruments is a leading Cone Crush Tester manufacturer and supplier in India. To get the best price, request a quote or call us now!
The instrument applies a controlled load to the specimen through a compression mechanism while a precision load cell measures the force generated during testing. The peak force provides an indication of the specimen's resistance to crushing & deformation.
Equipped with a microprocessor-based control system, digital display and peak hold facility, the tester supports convenient operation and reliable measurement. It is suitable for quality control laboratories, paper product manufacturers & packaging industries.
|
Parameter> |
Specification> |
|
Load Cell Capacity |
250 kgf (customisable on request) |
|
Accuracy |
±0.5% at full load (with master load) |
|
Dimensions |
600 × 500 × 863 mm |
|
Least Count / Resolution |
0.01 kgf |
|
Power Supply |
220 V, single-phase, 50 Hz |
|
Test Speed |
12.5 ± 2.5 mm/min |
|
Speed Drive |
Optional accessory |
|
Display |
Microprocessor-based digital display |
|
Peak Hold Facility |
Available |
|
Control System |
Smart logical control system |
|
Safety Features |
Upper and lower limit switches |
|
Material of Construction |
Mild steel, powder-coated body |
