The colors of the product play a very important in making the product more appealing. Thus, it is more important for you to use the right consistency of colors in the product. To ease the process of color assessment in the product, you can easily make the use of Testronix color matching cabinet. This is one of the authorized labs testing equipment designed by the experts at Testronix that will help you to assess the colors of the product in different light sources.

With the help of the Testronix color matching cabinet- Asia, you will be able to identify the difference in the color quality so that you can work on the potential areas of variability. Here in this blog, we are going to provide you with easy steps through which you can easily commence a test using color matching cabinet-Asia.

Color matching cabinet: Maintain the color consistency of products with ease

Measuring the color variance in certain products is one of the common practices that have been performed by various manufacturers and quality heads to improve their product quality. The products needed to be in the right consistency of colors so as to maintain the product color consistency. Color matching cabinet equipment is used in the textile industry and is suitable for almost all applications that require color consistency and quality. It is designed for the visual evaluation of color differences under standardized and controlled lighting conditions. Spectrum Asia provides a standardized and controlled environment for the visual assessment of colors. The color matching cabinet will show your product's true color.

Besides this, there are many advantages you will get with the use of a color-matching cabinet. You can read about the advantages of color matching cabinets and get to know how useful this product is. From ceramics to bottle testing, this amazing lab testing equipment can be used in various industries that require color consistency testing to get improved product quality.

Here are the features and technical specifications you will get with the use of this lab testing equipment.

Features of Testronix color matching cabinet- Asia

The color of materials depends on the geometric and special nature of the illuminating and viewing condition. This practice specifies the standard condition for appraising the colors and color differences of opaque specimens that are diffusely illuminated. Thus, you can easily match the consistency of colors under different light sources with Testronix color matching cabinet- Asia.

Below we have created a list of its features.

  • The equipment offers controlled and reproducible lighting conditions.There is a wide viewing area available in this testing instrument.Suitable for all applications, that demands color consistency and quality.It makes use of multiple light sources or lamps to detect the phenomenon of Metamerism.Various light sources include artificial daylight, cool white light, tungsten filament light,Ultraviolet blacklight, Triphosphor light.Gives you accurate testing results of color consistency.

These are the features of Testronix color matching cabinet-Asia. Now let us focus on its technical specifications.

Technical Specifications of Testronix color matching cabinet


The equipment is fitted with FIVE Light Sources as per CIE International Standards:

  • D – 65 – Artificial daylight – 2 Nos.
  • TFL Light-Tungsten Filament – 4 Nos.
  • TL – Light-Point of Sale – 1No.
  • UVB Light-Ultra Violet – 1 No.
  • CWF Light-Cool white fluorescent – 1 No.
  • Accuracy: ± 0.2%Least Count/Resolution: 1/10hThe angle of viewing booth – 45 degreeViewing Booth Material – Wood or SteelTime Totalizer – up to 10000 hoursViewing area: L 675 x W 455 x H 400 mm

Steps to commence test using Testronix color matching cabinet

If you want to test your product color consistency then we suggest you follow the below-mentioned steps. These steps will let you get accurate testing results.

  • Place the material at the bottom of a viewing booth at the distance from the illuminator required to obtain the specific luminance. The specimen should be viewed at a distance of 450 to 600mm (18” to 24”).
  • When viewing a glossy surface, it is necessary to avoid seeing the light source secularly reflected by the surface. This may be accomplished by illuminating along the normal to the surface and viewing at 45° C to the normal or illuminating at 45°.
  • The INCA Light consists of four incandescent bulbs. Assessment should be done under filament lighting to ensure that the two samples are still matching. It is this light under which Metamerism is detected. If the match is satisfactory, proceed on to the next light.
  • The U.V. Light switch should now be put ON to enable tests to be carried out under ultra–violet light. With the widespread use of fluorescent dyes and brighteners, it is necessary to ascertain if both samples react equally to ultra–violet radiation. It is often found particularly in the case of white samples the U.V.B. Light clearly indicates the presence of fluorescent dyes and bleaches.
  • A final test under TL-84 Triphosphor Fluorescent lamp is carried to ascertain if the colors are acceptable at the ‘Point of Sale’.
  • If the matching of both the samples holds well under all the lights. It means that the Dyeing, Printing, and coloring of the sample are as per the requirement.



In this way, you can easily commence the test with the help of this lab testing equipment. You can give us a call at +919313140140 or email us at info@testronixinstuments.com. Our team of technical experts will easily assist you with all your queries.
