How Does Testronix GSM Round Cutter Work?

Reviewed by Anurag Mishra (Sr. Technical Consultant)

Responsive image

Checking the grammage of samples like paper, a card, etc. is an essential part of the production. To check the grammage, you need to accurately cut the sample. Thus, by using the Testronix GSM round cutter, you will be able to cut your testing sample accurately and save time while significantly improving the product quality. In the textile industry, it is very important for you to test the grammage of materials in order to deliver quality products to the customers. This accurate cutting tool will cut the sample accurately in a circular shape so that you can easily check its grammage. Here is his blog, we are going to provide you with the information about the Testronix GSM round cutter and how you can accurately perform the test using this lab testing equipment.

Cut the sample precisely in a round shape using Testronix GSM round cutter

If you are looking for accurate testing equipment to cut the samples accurately in a round shape, then there is no best testing equipment other than the Testronix GSM round cutter. This precise testing equipment has been provided with 4 built-in knives that make it easy for you to cut the sample. By evolving the handling knob quarter of a turn, the cutter produces a circular sample of 100 cm². The GSM of several packaging materials like corrugated sheets, cardboard boxes, and other related items will be calculated accurately on the Testronix weighing balance once you cut the sample in a round shape.

Whenever you are ready to conduct the test using the Testronix GSM round cutter, you should read the instructions properly for setting up the machine. Most of the product quality heads will not read the instructions properly. As a result, they will get injured. Thus, it is important for you to conduct the test after reading the instruction manual.

Thus, it is essential for you to cut the sample accurately with the use of this lab testing equipment. To make your process much easier, we have embedded amazing features and technical specifications in this lab testing equipment. So, have a look at them below.

Features of Testronix GSM round cutter

A GSM round cutter is one of the effective testing equipment that will help you in the accurate cutting of testing samples. This round sample cutter is appropriate for cutting samples from paper, single layer board, foils, textiles, etc., and for cutting multi-layer board (corrugated board).

  • High-Quality Aluminum body
  • The lightweight and resilient structure
  • Provides Highly accurate test results
  • Heavy Duty robust Cutting Blades
  • Available with Safety Latch Facility
  • The main body is made of excellent quality aluminium casting.
  • A lock system is also provided for safety.
  • 2 No’s Special quality GSM pad is provided for support while cutting.
  • The machine is equipped with 4 nos. of replaceable German Blades.
  • The movement of the Hand Wheel is ¼ rounds to cut a sample.

Technical Specifications of Testronix GSM round cutter

  • Sample Area: 100 cm2Sample Diameter: 112.87mm
  • Type of Cut: Circular
  • Blade holders: 4 Nos. Stainless Steel
  • Cutting Blades: Heavy Duty Reversible German Blades
  • No. of Blades: 4
  • Safety Lock: Fine Brass Lock
  • Handle Wheel: Special Bakelite Handle
  • Cutting Pad: Rubber-Foam Pad
  • Size of Gray Cutting Pad: 300(L) x 200(W) x 21 (H)
  • Movement of Handwheel: ¼ Round to cut a sample
  • Linearity: +/- 0.01 g
  • Weighing balance capacity /least count: 600 g/ 0.01 g

With these features and technical specifications, you will be able to conduct the test accurately with a GSM round cutter. Now, let us discuss the working procedure of this amazing lab testing instrument. You can also read about the significance of this lab testing instrument in the packaging industry. Beside this you can also test the fabrics GSM by cutting accurately with GSM round cutter.

Working procedure of Testronix GSM round cutter

The GSM round cutter is delicate testing equipment that provides you with an easy cutting of samples. In order to conduct the test accurately with the GSM round cutter, you can follow the steps mentioned below.

  • You can start by placing the sample on a sample cutting pad.
  • After that, release or open the safety pin with slight pressure on the handle. This will bring internal blades in contact with the sample.
  • Rotate the handle under pressure and the specimen will be cut accurately.

In this way, you can easily cut the sample and check its grammage. For more information, about the GSM round cutter price, usage etc. give us a call at +91 9313 140 140 or email us at info@testronixintruments.com. The team of our technical experts will easily solve all your queries.
