HMI-Based Impulse Generator with Oscilloscope Price and Manufacturer in India

Description

The Impulse Generator simulates high-voltage transients such as lightning surges or switching impulses on equipment under test. It is essential for testing appliances in categories where impulse withstand capacity is critical. This version includes an attenuated oscilloscope output for waveform capture and digital diagnostics.

Features

Simulates standard lightning and overvoltage transients
HMI-based control ensures ease of setup and test repeatability
Built-in attenuated signal output for waveform analysis
Dual polarity testing in a single unit
Meets industry standards for surge immunity and dielectric protection

Specifications

Parameter	Specification
Mains Supply	230 V AC ±10%, 50 Hz
Impulse Voltage Range	±1 kV to ±10 kV
Impulse Rise Time	1.2 μs ± 30%
Impulse Duration	50 μs ± 20%
Polarity Selection	Positive and Negative
Output Type	Attenuated 0–10V output for oscilloscope
Oscilloscope Interface	BNC output compatible with most scopes
Control Panel	HMI-based sequence controller
Safety Interlocks	Yes
