How to Maintain Edge Crush Tester Effortlessly?

Reviewed by Anurag Mishra (Sr. Technical Consultant)

Responsive image

Most of the manufacturers in the packaging industry face the issue related to the edge crush of the materials like corrugated boxes. Small damage to packaging material like these boxes will lead to loss of product as well as the company’s reputation. Thus, to test the edge compression strength of these materials, you can easily make the use of Testronix edge crush tester digital model. This is one of the amazing testing instruments from Testronix that will help you to take three different tests before delivering your product to your customers. These tests include edge crush test, ring crush test, and flat crush test. This economical testing instrument has gained popularity in the packaging industry due to its advanced features. Here in this blog, we will discuss how the edge crush tester will help you in improving your corrugated box quality and how you can maintain it to use for a longer time.

What is an edge crush tester and how does it help to keep you ahead of the competition?

An edge crush tester is the best testing instrument that will help you to assess the edge-wise compression strength of materials like corrugated boxes, paper boards, etc. With the help of this test, you can evaluate the cross-direction crushing of samples. This crushing resistance of the samples will be evaluated in terms of kg/unit length. With its user-friendly controls and easy-to-access features, you can effortlessly take the edge crush test in a short span. Whenever you conduct this edge crush test then you must ensure to put the sample accurately so as to get accurate testing results.

The edge crush test is one of the reliable ways to test the edge-wise compression strength of the corrugated boxes. The main purpose of this testing instrument is to ensure that you do not face any product rejections due to poor-quality corrugated boxes. It comes with a fail-proof and rugged structure that makes it easy for you to conduct the test. With this testing instrument, you can store the peak value of the test results. If you wish to keep yourself ahead of competitors then using Testronix edge crush tester will serve to be useful.

Testronix Edge Crush tester features and specifications

As we have discussed above that edge crush tester will help you to get the value of edge-wise compression strength of the material, so you can use this testing machine with ease. Thus, with this edge crush test, you will be able to deliver high-quality products to your customers. You can also read about the importance of edge crush testers in the packaging industry.

Now, let us focus on the features and technical specifications of this testing instrument.

Features of edge crush tester digital

  • It comes with a microprocessor-based display for highly accurate testing results.
  • You can easily display compression test results.
  • It has separate fixtures for ring crush, edge crush, and flat crush test.
  • It has highly accurate testing results under compression force.
  • You can easily conduct the test with its feather touch controls and reveal the crushing resistance of the sample.
  • It comes with a powder-coated body with a corrosion-resistant finish.
  • The safety switch having upward and downward limit switches has also been embedded in this testing instrument.
  • Load Cell Capacity 100 Kgf
  • Accuracy ±2% at full load (with master load)

Technical Specifications

  • Maximum Load range: 100 kgf
  • Dimensions: 600x500x863 mm
  • Least Count/Resolution: 0.01 Kgf
  • Power: 220V Single phase, 50 Hz
  • Test Speed: 12.5± 2.5 mm/min

These are the features and technical specifications of the Testronix edge crush tester. The computerized model of this testing instrument will also be provided on request. You can also get thermal printer connectivity as an optional feature. Now, let’s focus on the tips to maintain your Testronix edge crush tester efficiently.

5 mind-blowing ways to maintain your Testronix edge crush tester

The crush test has become a necessity in the packaging industry to ensure error-free delivery of the products. This authentic testing instrument has been accredited with industry standards like IS 7063. If you wish to use this best-selling testing instrument for a longer time then we have listed 5 wonderful ways to maintain it. We’re sure that you will find these ways informative and use your testing instrument for a long.

  1. Earthing is a very important factor that plays a major role in keeping your testing instrument maintained. This forms an essential part of every installation process. Therefore, when you operate this testing machine, then we suggest you provide proper Earthing to the machine.
  2. Another most important part of the machine is its grips. Thus, you should ensure that the grips are perpendicular. You can easily check the perpendicularity of the machine every three months.
  3. The calibration of this testing instrument should be tested every six months. Thus, you can consult with our service expert and get your testing instrument calibrated.
  4. The V-belt of this testing machine should also be tested every three months to keep wear and tear away.
  5. You must ensure the right placement of specimen and ensure that all screws must be greased every three months. This will give you a smooth-sailing experience.

In this way, you can easily maintain your edge crush tester testing instrument. To get more information about the edge crush tester price, models, etc. you can give us a call at +91 9313 140 140 or email us at info@testronixinstruments.com. Our experts will get in touch with you and help to solve your query.
